Servo Tuber Machine: ZT 1962S
Well-designed, high-efficiency bottomer machine aimed at meeting diverse industrial manufacturing needs
Features:
- Stable long time running and highly precise.
- Equipped with an intuitive control panel, user-friendly interface that allows staff to quickly adapt to its operation.
Operating Conditions:
Working time: 20 hours / day
Design working environment temperature: 0 ~ 40 °C
Design working environment humidity: up to 95%
The Technical Parameters:
Tube length: 500 ~ 1100 mm
A -shaped edge tube width: 350 ~ 620 mm
M -shaped edge tube width: ≤80 mm
Cutter: Step cut / straight cut
Number of layers: 2-3layers of paper +1 film layer or paper layer
Maximum production speed: 180 tubes / min
Voltage and frequency: 380±10V 50H z
Equipment size: 28.72 * 2.38 * 2.875
